Ultrasonic Scanner

Ultrasonic Scanner Scanning Mode: mechanical sector scan Scanning Depth: 192mm Monitor Size:5.6-inch TFT-LCD Display Mode: B, B+B,B+M,M Image Gray Scale:256 levels Image Magnification: X1.0,X1.2,X1.2,X1.5,X2.0 M scanning speed: 2,4,6,8S/four gears each frame adjustable Probe frequency:2,5 MHz, 3.5MHz,5.0MHz three gears adjustable Measurement functions: distance, circumference, area, heart rate,animals' gestationmeasurement Character and Notes: case number, age, gender Video out: connect external video display and video printer Battery capacity: 2200mAh Mainframe power consumption:25W Weight: ≤1kg(including probe) Application in livestock production Monitoring follicle development and ovulation; barren sows as early as 18 days and barren cows as early as 28 days after breeding; stillbirth, abortion, embryo absorption, etc. and estimate the number of embryos; fetus' vitality and whether the membrane is drained; the recovery of uterus and diseases such as endometritis, pyometra, effusion, etc. Conducting backfat levels and eye muscles' areas determinations on living animals to provide accurate data for the breeding of parent pigs and the appraisal of breed quality Application in pet disease Clinical ultrasound examinations for tumors, calculuses, cyst, abscess, inflammation of dogs’ and cats’ liver, gallbladder, spleen, pancreas, etc.; tumors, obstruction, intussuception, foreign matters in cats' and dogs’ gastrointestinal tract; tumors, calculuses, dilatation, stricture and inflammation of dogs’ and cats' kidney, bladder, ureter and urethra; tumors, calculuses, effusion, empyema, inflammation, etc. of dogs’ and cats’ uterus, ovary and prostate.
